Vehicle Description
(according to 1999 ACO Le Mans Regulations)

Engine

• six cylinder boxer engine
• 3600 cc 76.4 mm. stroke, 100mm bore
• maximum torque 380 Nm @ 7000 rpm
• power 300 KW (410 HP) @ 8200 rpm with 43.1 mm restrictor
• maximum rpm 8500
• water cooled with oil heat exchanger
• dry-sump lubrication
• intake system with six throttle valves
• Bosch MS 3.1 fuel injection with detonation control
• exhaust manifold open, without catalytic converter
• 108 RON octane leaded fuel

Power Train

• six speed manual transmission type G96/61 with oil cooler
• cable controlled gear shift mechanism
• rear wheel drive
• single mass flywheel with racing clutch
• limited slip differential -- 40/65%
• gear ratios (as delivered)
  • ring and pinion 7/35
  • 1st gear 13/41
  • 2nd gear 20/40
  • 3rd gear 25/29
  • 4th gear 29/36
  • 5th gear 32/33
  • 6th gear 35/30

Bodywork

• revised 996 chassis with front and rear composite fender flares
• composite front nose, front fenders, front and rear hood, doors, rear tail and rear lid
• aerodynamically optimized front nose and rear tail
• welded-in safety roll cage
• racing bucket seat (driver only)
• six-point seat belt/harness
• MOMO steering wheel
• fire extinguisher
• 100 liter FT 3 safety fuel cell
• air jacks
• plastic door, side and rear windows

Suspension

• electrically actuated power steering
• McPherson front suspension with ball joints
• multilink rear axle with ball joints
• coil spring with adjustable ride height and rate
• Bilstein adjustable shock absorbers
• wheels three piece BBS
  • front - 10" X 18"
  • rear - 11" X 18"
• Pirelli rain tires
  • front 265/645 X 18
  • rear 295/680 X 18
• center lock hubs/wheels
• front roll bar adjustable in five positions
• rear roll bar adjustable in three positions
• drive shafts with CV joints

Brake System

• twin pedal system with two master cylinders and balance bar
• internally vented brake discs
  • front - 380mm diameter
  • rear - 355 mm diameter
• no ABS

Electronics

• Bosch MS 3.1 engine management
• Stack display with integrated data recording (data recording device: optional)
• lap trigger over Stack display
• 12V 50 Ah battery
• alternator 110 amp

Vehicle weight      Approximately 1,100 kg (2442 lb.) per Le Mans Regulations

Delivery     December through March 2000

Color Exterior and interior Biarritz white Z2
