Bil |
Porsche 911 S , Tävlings utrustad för roadsport & PCS Racing. |
|
Årsmodell |
1974. |
|
Motor |
3,2 liter Carrera 1987. |
|
Effekt |
231 hk. |
|
Avgassystem |
SSI headers 2x4 tum JP slutrör, Pipercross luftfilter. |
|
Transmission |
5 vxl Porsche shortskift. |
|
Hjulupphängning |
Sänkt 30mm, Bilstein clubsport dämpare, Bak, 22mm Weltmeister kränghämmare, 29mm torrisionsstavar, fram 15mm kränghämmare, 19mm torrisionsstavar, turbo styrstag, Jamex fjäderbensstag, Weltmeister polygrafitbussningar. |
|
Fälgar |
Fuchs 7&8 / 15 tum. 3mm spacers fram. |
|
Däck |
Pirelli P zero c dry,205 fram, 225 bak. |
|
Bromsar |
Fram C2 ok, 24mm skivor. Bak C3,2 framok, 24mm skivor, Pagid belägg runt om, rostfria bromsslangar. |
|
Bur |
Godkänd OMP. |
|
Vikt |
1080 kg |
|
Ägare |
Fredrik Bratt |
|
Klubbar |
Porsche club Sverige, PCS Racing, Jönköpings-spotvagnsklubb, Nya Anderstorp racing club. |
|
Team |
Giraffen Racing. |
| Chassis: | Unitary,all-steel monocoque body, fully galvanized, Two door coupé, Roll cage. | |
|---|---|---|
| Body work: | Based on 911 carrera -77 with additional plastic front fenders, Adjustable 3.8 RSR plastic rear wing, Front lid and doors in plastic,Additional front spoiler, C2 Front and rear bumpers and Light Package,RSR(RUF) Mirrors, Thin Lexan MR5 Aircraft Quality window (7pc), No rear window heater, Hood latches, Front dome cross bar. | |
| Interior: | Momo Racing seat 12,3 Lbs/ 5,6 kg, Momo Racing Steering Wheel, black suede 350mm(Porsche design), Lap timer, Thats it ! | |
| Engine: | Highly tuned Air-cooled ,longitudinal flat six-cylinder boxer,chain driven single overhead cams,rocker arms,Custom cam grinds (mühlbauer Racing), Modified pistons, Dry-sump lubrication,Twin ignition, Electronic/digital (Bosch Motronic M1,2 fuel injection/ignion) Engine Management ,Covered by knock regulation ,Sequential multi-point intake pipes, fuel injection for unleaded 98 Octane, Cupcar (solid) motor mounts. | |
| Number of cylinders: | 6 | |
| Valves per cylinder: | 2 | |
| Displacement, mm: | 3600 cc | |
| Stroke, mm: | 76.4 mm | |
| Bore, mm: | 100 mm | |
| Compression: | 11,3:1 | Max output bhp / rpm: | + 300 / 6100 |
| Firing order: | 1-6-2-4-3-5 | Engine lubrication: | Dry sump system with separate oil tank,Full-flow oil filter. |
| Dimension: | ||
| Length: | 168.94 in. (4291 mm) | |
| Width: | 65.04 in. (1652 mm) | |
| Height at curb weight: | 51.97 in. (1320 mm) | |
| Wheel base: | 89.45 in. (2272 mm) | |
| Front track: | 55.45 in (1417 mm) | |
| Rear track: | 56.80 in. (1558 mm) | Ground clearance: | Less than 3 in. |
| Weights: | ||
| Curb weight: | ? lbs. ( ? kg ) | Transmission: | G50/03 Five-speed Manual gearbox in unit with rear Engine via centered Racing (Turbo) clutch with Singelmass lightweight RSR flywheel (cup car clutch package) Limited-slip differential, 40 % locking under load power and 65 % locking under deacceleration. | 1st gear: | 3,500 |
| 2nd gear: | 2,059 | 3rd gear: | 1,407 |
| 4th gear: | 1,086 | |
| 5th gear: | 0,868 | reverse | ? | Suspension: | Front: | McPherson front struts (RSR) and custom valved Koni RSR Adjustable shock Absobers with mono ball upper mounts,Fully adjustable stabilizer (sway bar) 22 mm. |
| Rear: | Original Cup car suspension (bilstein)Mac Pehrson coil over whit rear 935 spring plats, Adjustable stabilizer (sway bar). | |
| Bushes: | Uniball joint/ Poly Grafit. | |
| Braking System: | Front: | Brembo RS Four-Piston fixed-saddel. |
| Ventilated and cross bored discs 13". | ||
| Rear: | Brembo 911 Turbo 3.3 front caliper. | |
| Ventilated and cross bored discs. | ||
| Pads: | Pagid. | Dual pedal,Triple cylinder brake and clutch assembly with balance bar/dual Master cylinders 5/8 (Nascar Approved) with remote cable adjuster.Stainless steel brake lines. |
| Steering: | Rack and pinion steering assembly with turbo tie rod kit. | |
| Fuel tank: | -72 Plastic tank with fuel tank foam. 80 litre capacity. | |
| Wheels and Tyres: | Front: | 8 J x 17 Original light Cup alloy wheels. |
| 245-620-17 Racing Slicks. | ||
| Rear: | 9,5 J x 17 Original light Cup alloy wheel. | |
| 265-640-17 Racing Slicks. | ||
| Front and Rear : | Spacer. | |
| Safety : | 6 point hardness with Aircraft quick release buckle,Dry chemical Fire extinguisher alloy bottle 2,5 kg, Battery master switch,Removal steering wheel. | |
Teknisk data kommer att komma över teamets övriga bilar.
